8B0C0160HW00-0011 B&R

Category: Motion control > ACOPOSmulti > Auxiliary supply modules 400W > Wall mounting

Connections for supplying external 24 V devices Extensive protective measures ACOPOSmulti auxiliary supply module, 16 A, AS, wall mounting, 24 VOut 1x 16 A, 1x 5 A.

Technical Specifications

General information

• Certifications
• CE = Yes
• UKCA = Yes
• CRA (Cyber Resilience Act) = In preparation
• UL = cULus E225616 Power conversion equipment
• KC = Yes
• Cooling and mounting type = Wall mounting

DC bus connection

• Voltage
• Nominal = 750 VDC
• Operating range in continuous operation = 260 to 800 VDC
• Full continuous power = 315 to 800 VDC
• Continuous power consumption = Max. 445 W
• Power dissipation with continuous power = 22 W (0% continuous power) 27 W (50% continuous power) 45 W (100% continuous power)
• DC bus capacitance = 220 nF
• Variant = ACOPOSmulti backplane

24 VDC output

• Output voltage
• DC bus voltage (U DC ): 260 to 315 VDC = 25 VDC * (U DC / 315)
• DC bus voltage (U DC ): 315 to 800 VDC = 24 VDC ±6%
• Reduction of continuous power depending on installation elevation
• Starting at 500 m above sea level = 40 W per 1000 m
• Terminal connection cross section of 24 VDC Out 1 output
• Flexible and fine-stranded wires
• With wire end sleeve = 0.5 to 6 mm²
• Approbation data
• UL/C-UL-US = 22 to 10 AWG
• CSA = 22 to 10 AWG
• Terminal connection cross section of 24 VDC Out 2 output
• With wire end sleeve = 0.2 to 2.5 mm²
• UL/C-UL-US = 22 to 12 AWG
• CSA = 22 to 12 AWG
• Continuous power = 400 W
• Continuous current = 16 ADC
• Reduction of continuous power at ambient temperatures starting at 40°C = No reduction
• Reduction of continuous power depending on cooling method = No reduction
• Startup delay = Max. 1 s
• Startup time = Approx. 5 to 20 ms
• Residual ripple = Typ. 50 mV SS

24 VDC internal system power supply

• Peak current (<4 s)
• DC bus voltage (U DC ): 350 to 800 VDC = 21 ADC
• Protective measures
• No-load proof = Yes
• Overload-proof = Yes
• Short-circuit proof = Yes
• Feedback protection = Max. 26 VDC (also when the power is switched off)
• Overtemperature protection = Yes
• Dielectric strength to ground = ±50 VDC
• Output/Input isolation = SELV / PELV requirements
• Output voltage = 25 VDC ±1.6%
• Variant = ACOPOSmulti backplane

24 VDC Out

• Output voltage
• DC bus voltage (U DC ): 260 to 315 VDC = 25 VDC * (U DC / 315)
• DC bus voltage (U DC ): 315 to 800 VDC = 24 VDC ±6%
• Protective measures
• No-load proof = Yes
• Overload-proof = Yes
• Short-circuit proof = Yes
• Feedback protection = Max. 35 VDC (also when the power is switched off)
• Overtemperature protection = Yes
• Dielectric strength to ground = ±50 VDC
• Output/Input isolation = SELV / PELV requirements
• Variant
• 24 VDC, COM = Connector
• Protection of 24 VDC Out 1 output = 16 A (slow-blow) electronic, automatic reset
• Protection of 24 VDC Out 2 output = 5 A (slow-blow) electronic, automatic reset

24 VDC Out 1 controller input

• Electrical isolation
• Input - 24 VDC = Yes
• Input voltage
• Nominal = 24 VDC
• Maximum = 30 VDC
• Switching threshold
• Low (24 VDC Out 1 is switched on) = <5 V
• High (24 VDC Out 1 is switched off) = >15 V
• Switching delay
• ON (24 VDC Out 1 is switched on) = Max. 25 ms
• OFF (24 VDC Out 1 is switched off) = Max. 0.25 ms
• Terminal connection cross sections
• Flexible and fine-stranded wires
• With wire end sleeve = 0.2 to 2.5 mm²
• Approbation data
• UL/C-UL-US = 30 to 12 AWG
• CSA = 22 to 12 AWG
• Circuit = Sink
• Modulation compared to ground potential = Max. ±50 V
• Input current at nominal voltage = Approx. 10 mA
• Variant = Connector

Operating conditions

• Permissible mounting orientations
• Hanging vertically = Yes
• Horizontal, face up = Yes
• Standing horizontally = No
• Installation elevation above sea level
• Nominal = 0 to 500 m
• Maximum = 4000 m
• Pollution degree per EN 61800-5-1 = 2 (non-conductive pollution)
• Overvoltage category per EN 61800-5-1 = III
• Degree of protection per EN 60529 = IP20
