80PS080X3-1001 B&R

Category: Motion control > ACOPOSmicro > Power supply modules

Input: 3x 380 to 480 VAC ±10% Output voltage adjustable via X2X Link Status information readable via X2X Link Chopper output for connecting an external braking resistor 3-phase wide range input Closed metal housing Power supply module, Input 3x 380-480 VAC ±10%, Power output 24-80 VDC 16.6 A (max.

1000 W), Output 24 VDC 2 A, X2X Link interface, integrated brake chopper, wall mounting. Order terminal blocks separately!.

Technical Specifications

General information

• Power consumption
• Bus = 0.8 W
• Electrical isolation
• Mains input - Power output = Yes
• Mains input - 24 VDC = Yes
• Power output - 24 VDC = No
• X2X Link - Mains input = Yes
• X2X Link - Power output = Yes
• X2X Link - 24 VDC = Yes
• Certifications
• CE = Yes
• UKCA = Yes
• CRA (Cyber Resilience Act) = In preparation
• UL = cULus E225616 Power conversion equipment
• KC = Yes
• B&R ID code = 0xA7A9
• Status LED = Yes
• Connection type = Maximum 25 m line length to the power supply module

Mains input

• Fuse protection
• Internal = Each phase internally fused (5 A)
• External = External fuse required for line protection
• Input voltage range = 3x 380 to 480 VAC ±10%
• Input current at full load = 3x 2.2 A at 400 VAC 3x 1.8 A at 480 VAC
• Frequency range of mains voltage = 50 to 60 Hz ±5%
• Phase failure detector = Yes
• Power failure bypass = 10 ms (at full load)
• Power factor (cos φ) = 0.72 @ 400 V 1 kW 0.69 @ 480 V 1 kW
• Leakage current to PE = <3.5 mA
• Protective circuit = Transient surge protection with varistor

Power output

• Output current
• 24 to 60 VDC = Max. 16.6 A continuous current
• 60 to 80 VDC = Max. 16.6 to 12.5 A continuous current
• Overload/Pulse capacity
• Overload current = 20% overcurrent
• Overload duration = 2 s
• Output power = Max. 1000 W continuous power
• Output protection = Short-circuit, overload and no-load proof
• Control accuracy = ±2%
• Power back immunity = Yes, <100 VDC
• Output voltage = 24 to 80 VDC
• Switch-on time = <5 s (does not apply during firmware update)
• Parallel connection = Yes, max. 3 power supply units, for redundancy and increased power
• Series connection = No
• Max. capacitive load = Unlimited

24 VDC voltage output

• Voltage range = 24 VDC ±10%
• Output current = Max. 2 A continuous current
• Output protection = Short-circuit, overload and no-load proof
• Parallel connection = No

Chopper output

• Output current / Output power
• Continuous current / Continuous power = 30 A
• Maximum current / Maximum power = 40 A
• Response threshold for chopper activation = 29 to 95 VDC (adjustable)
• Overtemperature protection (chopper-internal) = Yes

Interfaces

• User interface
• Variant = 10-pin terminal block
• Type = X2X Link
• Min. X2X Link cycle time = 250 µs

Efficiency, reliability

• Power dissipation
• Rated load = 90 W
• No-load operation = 30 W
• Efficiency = >92%

Operating conditions

• Mounting orientation
• Vertical = Yes
• Ventilation/Cooling = Internally controlled fan
• Degree of protection per EN 60529 = IP20

Ambient conditions

• Temperature
• Operation = 0 to 50°C
• Storage = -25 to 85°C
• Transport = -25 to 85°C
• Relative humidity
• Operation = 5 to 95%, non-condensing
• Storage = 5 to 95%, non-condensing
• Transport = 5 to 95%, non-condensing

Mechanical properties

• Dimensions
• Width = 67.5 mm
• Height = 257 mm
• Depth = 219 mm
• Material = Robust metal housing
• Weight = 3.75 kg
