B&R

3EX450-66-1 B&R

SKU: 3EX450-66-1
(0)
$3,100.03
In stock
Usually ships within 24 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 15221245849

Category: To Confirm

2005 bus controller, PROFIBUS DP master, galvanically isolated RS485 interface, max. 12 Mbit/s, max.

3.5 kB input data and max. 3.5 kB output data, RS232 configuration interface.

Technical Specifications

Short description

  • Bus controller = PROFIBUS DP master

General information

  • Diagnostics
  • Module status = Yes, using LED status indicator
  • Bus function = Yes, using LED status indicator
  • RS232 data transfer = Yes, using LED status indicator
  • Power consumption
  • 24 VDC = 1.1 W
  • 5 VDC = 4.4 W
  • Total = 5.5 W
  • Electrical isolation
  • IF1 - IF2 = Yes
  • PLC - IF1 = No
  • PLC - IF2 = Yes
  • Certifications
  • CE = Yes
  • UKCA = Yes
  • UL = cULus E115267 Industrial control equipment
  • Status indicators = Transmit/Receive data for RS232, bus function, module status

Interfaces

  • Interface IF1
  • Type = Fieldbus configurator online interface RS232
  • Variant = 9-pin male DSUB connector
  • Max. transfer rate = 9.6 kbit/s
  • Interface IF2
  • Fieldbus = PROFIBUS DP master
  • Type = RS485
  • Variant = 9-pin female DSUB connector
  • Number of slaves = 125
  • Max. transfer rate = 12 Mbit/s

Operating conditions

  • Degree of protection per EN 60529 = IP20

Ambient conditions

  • Temperature
  • Operation = 0 to 55°C
  • Storage = -25 to 70°C
  • Relative humidity
  • Operation = 5 to 95%

Mechanical properties

  • Dimensions
  • Width = System 2005 single-width
  • Slot
  • Base unit = Yes
  • Expansion unit = No
  • Note = Order fieldbus configurator separately
