B&R

3DO486-6 B&R

SKU: 3DO486-6
(0)
$1,201.59
In stock
Usually ships within 24 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 15221245849

Category: To Confirm

2005 digital output module, 32 transistor outputs 24 VDC, 0.5 A, 2 electrically isolated output groups, order 2x terminal block TB718 separately!.

Technical Specifications

Short description

  • I/O module = 16 digital outputs 24 VDC in 2 groups

General information

  • Diagnostics
  • Outputs = Yes, using LED status indicator
  • Operating state of outputs = Yes, using LED status indicator
  • Power consumption
  • Internal
  • 24 VDC = -
  • 5 VDC = 1.0 W
  • Total = 1.0 W
  • External 24 V = 4.0 W
  • Electrical isolation
  • Group - Group = Yes
  • Channel - Channel = No (same group)
  • Channel - PLC = Yes
  • Certifications
  • CE = Yes
  • UKCA = Yes
  • UL = cULus E115267 Industrial control equipment
  • Status indicators = I/O function per channel, operating state of the outputs

Digital outputs

  • Nominal voltage = 24 VDC
  • Nominal output current = 0.5 A
  • Total nominal current = 8.0 A
  • Output circuit = Source
  • Output protection = Thermal shutdown in the event of overcurrent or short circuit, integrated protection for switching inductive loads, reverse polarity protection of the output power supply
  • Group rated voltage = 4.0 A

Operating conditions

  • Degree of protection per EN 60529 = IP20

Ambient conditions

  • Temperature
  • Operation = 0 to 60°C
  • Storage = -25 to 70°C
  • Relative humidity
  • Operation = 5 to 95%

Mechanical properties

  • Dimensions
  • Width = System 2005 single-width
  • Can be installed on
  • Base unit = Yes
  • Expansion unit = Yes
  • Note = Order 1x terminal block TB170 separately.
