3DM455-60-2 B&R

Category: To Confirm

2005 digital mixed module, 8 inputs 24 VDC, 2.5 µs, sink, 8 transistor outputs, 0 to 50 VDC, 1 A, order 1x terminal block TB170 separately!.

Technical Specifications

Short description

• I/O module = 8 digital inputs, 8 digital outputs

General information

• Diagnostics
• Outputs = Yes, using LED status indicator
• Error = Yes, using LED status indicator
• Initialization = Yes, using LED status indicator
• Power consumption
• 24 VDC = -
• 5 VDC = 3.5 W
• Total = 3.5 W
• Electrical isolation
• Group isolation = Input group - Output group
• Channel - Channel = No
• Channel - PLC = Yes
• Certifications
• CE = Yes
• UKCA = Yes
• UL = cULus E115267 Industrial control equipment
• Status indicators = Initialization, error, I/O function per channel

Digital inputs

• Input filter
• Hardware = ≤2.5 µs
• Software = -
• Nominal voltage = 24 VDC
• Input circuit = Sink
• Additional functions = Encoder evaluation, signal measurement, high-speed signal processing

Digital outputs

• Nominal output current
• Motor operation = See section "Permissible load on the motor winding".
• Push, pull, push/pull = 1.0 A
• Output circuit = Push, pull, push/pull, full-bridge
• Output protection = Thermal shutdown in the event of overcurrent or short circuit, integrated protection for switching inductive loads, reverse polarity protection of the output power supply
• Sensor power supply = External
• Supply voltage = 0 to 50 VDC
• Additional functions = Stepper motor control, pulse width modulation

Operating conditions

• Degree of protection per EN 60529 = IP20

Ambient conditions

• Temperature
• Operation = 0 to 60°C
• Storage = -25 to 70°C
• Relative humidity
• Operation = 5 to 95%

Mechanical properties

• Dimensions
• Width = System 2005 single-width
• Can be installed on
• Base unit = Yes
• Expansion unit = Yes
• Note = Order 1x terminal block TB170 separately.
